Removing Misfed Paper

89

5

LLLL

If your printer is equipped with
both the Finisher SR730 and the
Mailbox CS360, open the triangu-
lar cover on the front of the Mail-
box CS360.

MMMM

Turn the blue lever W4 counter-
clockwise to open the cover (

A

A

A

A),

and then remove the misfed pa-
per (

B

B

B

B).

NNNN

Turn the blue lever W4 clockwise
to return the cover to its original
position.

OOOO

Close the triangular cover and the
front cover of the Mailbox CS360.

When "Remove Misfeed
Z:Duplex Unit" Appears

AAAA

Open the Bypass Tray and the
Duplex Unit right cover, and then
remove the misfed paper.

BBBB

Close the Duplex Unit right cov-
er.

CCCC

Open the Duplex Unit by push-
ing the catch upwards (

A

A

A

A).

TAPY490E

TAPY500E
