Ricoh AP4510 - Manual (Page 150)

Troubleshooting
76
5
Possible Cause Solutions
Is the Data In indicator
blinking or lit after starting
the print job? If not blinking or lit, the data is not being sent to the printer.
❖ ❖ ❖ ❖ If the printer is connected to the computer using the in-
terface cable
Make sure the printer port settings are correct. For a parallel
port connection, port LPT1 or LPT2 should be set.
• Windows 95/98/Me
A Click [Start], point to [Settings], and then click [Printers].
B Click to select the icon of the printer. Next, on the [File]
menu, click [Properties].
C Click the [Details] tab.
D Check the [Print to the following port] box to confirm that
the correct port is selected.
• Windows 2000
A Click [Start], point to [Settings], and then click [Printers].
B Click to select the icon of the printer. Next, on the [File]
menu, click [Properties].
C Click the [Port] tab.
D Check the [Print to the following port] box to confirm that
the correct port is selected.
• Windows NT 4.0
A Click [Start], point to [Settings], and then click [Printers].
B Click to select the icon of the printer. Next, on the [File]
menu, click [Properties].
C Click the [Port] tab.
D Check the [Print to the following port] box to confirm that
the correct port is selected.
❖ ❖ ❖ ❖ Network Connection
Contact your network administrator.
Do you print via a net-
work? Confirm that the "Ethernet" setting is correct from the control pan-
el. See p.122 “Host Interface Menu”.
The setting governs the data transfer speed used by the Network
Interface Board. Three options are available:
• Auto (default)
• 100 Mbps
• 10 Mbps
Note
❒ For details about the appropriate setting to use on your net-
work, contact your network administrator.
