Error & Status Messages on the Control Panel
71
5
Not Detected: Duplex Unit The optional Duplex Unit is
not set correctly. Set the optional Duplex Unit
correctly. If the message ap-
pears again, call your sales or
service representative.
Not Detected: Fusing Unit The fusing unit is not set cor-
rectly. Set the fusing unit correctly. If
the message appears again,
call your sales or service rep-
resentative.
Not Detected: User Selected
Tray The selected tray is not set cor-
rectly. Set the selected tray correctly.
If the message appears again,
call your sales or service rep-
resentative.
Paper in Duplex Unit There is paper in the Duplex
Unit. Remove paper from the Du-
plex Unit.
Paper in Finisher There is paper in the optional
Finisher SR730. Remove paper from the Fin-
isher.
Paper Misfeed: Duplex Unit There is misfeed in the Duplex
Unit. Remove the misfed paper. See
p.89 “When "Remove Misfeed
Z:Duplex Unit" Appears”.
Paper Misfeed: Finisher There is misfeed in the option-
al Finisher. Remove the misfed paper. See
p.84 “When "Remove Misfeed
R:Finisher" Appears”.
Paper Misfeed: Input Tray There is misfeed in the printer. Remove the misfed paper. See
p.80 “When "Remove Misfeed
A,Y:Input Tray" Appears”.
Paper Misfeed: Internal There is misfeed in the printer. Remove the misfed paper. See
p.82 “When "Remove Misfeed
B,C,D:Internal" Appears”.
Paper Misfeed: LCT There is misfeed in the option-
al Large Capacity Tray. Remove the misfed paper. See
p.86 “When "Remove Misfeed
U:LCT" Appears”.
Paper Misfeed: Mailbox There is misfeed in the Mail-
box. Remove the misfed paper. See
p.87 “When "Remove Misfeed
W:Mailbox" Appears”.
Printer is not ready An error has occurred in the
printer. Solve the problem to make
prints.
Ready The printer is ready for use. No action is required.
Replace Maintenance Kit It is time to replace parts in-
cluded in the Maintenance
Kit. Replace parts.
Warming Up The printer is warming up. Wait until "Ready" appears on
the panel display.
Messages Description Solution
