UNIX Configuration

HP-UX

❖

❖ Adding the IP address and host name to the /etc/hosts file

The following line is added to the /etc/hosts file. The IP address and printer
host name which you previously entered in the installation script will be
used.
192.168.15.16 np # Network Printer

• 192.168.15.16 is the IP address, np is the host name, from # to the end of the

line is a comment.

Note

❒ The /etc/hosts file contains a list of the IP addresses and their host names

of all of the hosts communicating on the network. Each entry is delimited
with a space or a tab, and each line is separated with a return.

❒ If you do not use NIS or DNS, you must manually enter the IP address and

host name of each workstation using the network printer in the /etc/hosts
file.

❖

❖ Registering the printer

The installation shell script registers the printer as a remote printer following
the procedure below.

Stop the scheduler.

/usr/lib/lpshut

/usr/lib/lpadmin -Pnp -v/dev/null -mrmodel

-ormnphost -orp"option" -ob3

• np is the printer name, nphost is the host name.

For more information about “option”, see p.16 “Specifying the Device
Option”.
“lp” will be assigned, if the option is not used.

Set the printer so that the print job is listed in the print queue.

/usr/lib/accept np

Set the printer to perform the print job.

/usr/lib/enable np

Restart the scheduler.

/usr/lib/lpsched
