Troubleshooting

94

5

Removing Jammed Staples

If staples do not eject properly, they
might be jammed.

Note

❒ Staples might be jammed because

of curled paper. In this case, try
turning the paper over in the tray.

❒ After removing the jammed sta-

ples, staples might not be ejected
for the first few times.

Finisher SR720

AAAA

Slide the stack unit of the Finish-
er SR720 out until it stops.

BBBB

Remove the staple cartridge.

CCCC

Open the face plate.

DDDD

Remove the jammed staples.

EEEE

Close the face plate.

FFFF

Slide the staple cartridge in until
it clicks.

GGGG

Slide the stack unit into the Fin-
isher SR720.

TAPY670E

TAPY680E

TAPY730E

TAPY740E

TAPY720E
