Installing Options
29
2
- - - -1394 Interface Unit
specification
❖ ❖ ❖ ❖ Operating System:
Windows 2000 Service Pack 1 or
later (when connecting with SCSI
print)
Windows Me (when connecting
with IP over 1394)
❖ ❖ ❖ ❖ Interface:
IEEE Std 1394-1995 compliant,
IEEE Std 1394a-2000 compliant
❖ ❖ ❖ ❖ Interface Connector:
IEEE 1394 (6–pin × 2)
❖ ❖ ❖ ❖ Data Transmission:
400 Mbps (maximum)
❖ ❖ ❖ ❖ Required cable:
1394 interface cable (6–pin x 4–pin,
6–pin x 6–pin)
Important
❒ You cannot plug devices togeth-
er to create loops.
❒ Do not use a cable more than 4.5
meters (14.8 feet) long.
❖ ❖ ❖ ❖ Connectable number of devices in a
bus:
Maximum 63
❖ ❖ ❖ ❖ Allowed cable hops in a bus:
Maximum 16
❖ ❖ ❖ ❖ Length of cable:
4.5 meters (maximum per hop)
❖ ❖ ❖ ❖ Power supply:
Non power supply
Cable Power repeated (IEEE1394a-
2000 compliant)
❖ ❖ ❖ ❖ Power repeat:
IEEE Std 1394a-2000 compliant
