Troubleshooting
88
5
DDDD
While opening the W2 cover (
A A A A),
remove the misfed paper (
B B B B).
EEEE
Push the blue button W3 to open
the cover (
A A A A), and then remove
the misfed paper (
B B B B).
FFFF
Close the cover and press it down
until it clicks into place.
GGGG
Open the top cover of the Mailbox
CS360.
HHHH
Pull the blue lever W5 to the right
to open the cover (
A A A A), and then re-
move the misfed paper (
B B B B).
IIII
Return the cover to its original po-
sition.
JJJJ
While pulling the blue lever W6
upwards (
A A A A), remove the misfed
paper (
B B B B).
KKKK
Remove the misfed paper from
the output tray.
TAPY430E
TAPY440E
TAPY450E
TAPY460E
TAPY470E
TAPY480E
