8.1 List
3-324
8
Chapter 8 Programming Examples
8.1 List
Instruction Program title Reference
Page
TMR, TMH, TMS [Timers] One-shot circuit 3-326
Off-delay circuit 3-326
On-delay circuit 3-327
Flicker circuit 3-327
C [Counter] Accumulator timer 3-327
Large capacity counter 3-328
Multi-level Up/Down counter 3-328
Counter multi-level setting 3-328
DIFU, DIFD One-shot circuit 3-329
KEEP Detection of packs on conveyor 3-329
SFT Alternating circuit 3-330
Repeat shift circuit 3-331
Asynchronous shift register 3-331
Resetting internal utility relays 3-332
HSP High-speed fetching of input data 3-332
MC-MCR Emergency stop circuit 3-333
W-UE Input sequence check 3-334
Fork lift truck IN/OUT judgement 3-334
STG-JMP Enabling double coil 3-335
Conditional branching 3-335
STP-STE Process progression 3-336
ITVL Pulse interval measurement 3-336
Fetching data from KV-AN6 3-337
CTH [High-speed counter] High-speed counter multi-level setting 3-338
High-speed counter current value clear 3-339
Input of phase differential signal 3-339
SBN [Sub-routine] DM shift 3-340
FOR-NEXT Transfer of a block of DM data 3-341
HKEY Fetching 16-key input 3-342
TMIN [Analog timer] Changing timer setting value 3-343
Changing setting values of multiple timers 3-343
LDA/STA First-in first-out (FIFO) 3-343
Changing the counter setting value 3-345
Changing the timer setting value 3-345
CMP Comparing values with no specific range 3-345
Setting the upper/lower limit 3-345
Changing the CMP setting value 3-346
Multi-level comparator 3-346
ADD Adding BCD and BIN(binary) values 3-347
Total count 3-348
SUB Comparison of absolute values 3-348
MUL Multiplying the counter current value by DM value 3-349
DIV Total count average 3-349
ANDA BCD (1-digit) input 3-350
Fetches input data separately 3-350
ORA Output of 2-digit BCD data 3-351
Separate input of 2-digit BCD 3-351
