6.2 High-speed Counters
KV
-300
KV-10/80
3-277
1 6
Chapter 6 Interrupts, High-speed Counters, Positioning Control
Utility relays for high-speed counter CTH1
2200 Internal clock (1.0 µs) for CTH1
2201 Internal clock (10.0 µs) for CTH1
2202 Internal clock (100.0 µs) for CTH1
2203 When comparator CTC2 is ON, automatically clears CTH1.
1: Yes 0: No
2204 Direct output to 0501 through comparator CTC2
1: Enable 0: Disable
2205 Direct output level to 0501 through comparator CTC2
1: ON 0: OFF
2206 Selection of INT3 edge
0: UP edge 1: DOWN edge
2207 Reverse output (toggle) level
1: ON 0: OFF
2208 Direct output to 0501 Direct output level to 0501 through comparator
1: Disable 0: Enable CTC3 (any one of these is ON)
2209 Turns OFF output to 0501.
1: Yes 0: No
2210 Turns ON output to 0501.
1: Yes 0: No
2211 Reverses output (toggle) to 0501.
1: Yes 0: No
2212 When comparator CTC3 is ON, automatically clears CTH1.
1: Yes 0: No
2213 Uses CTH1 in magnification mode.
1: Yes 0: No
2214 Selection of magnification mode for CTH1
1: x 4 0: x 2
2215 Enables external reset for CTH1.
1: Yes 0: No
For KV-10/80 users
1. KV-10/80 has one 8-bit (CTH0) and one 16-bit (CTH1) single phase counter.
2. Internal clocks are as follows:
3. Special utility relays of 2112, 2113, 2114, 2115, 2212, 2213, 2214, and 2215
are not available.
2100 0.8 µs 2200 0.4 µs
2101 6.4 µs 2201 0.8 µs
2102 102.4 µs 2202 3.2 µs
