Chapter 3
Interrupts
The interrupt processing function executes an interrupt program when an external
input or request from the high-speed counter comparator (interrupt factor) is encoun-
tered during KV operation.
This chapter describes the types of interrupt factors as well as inputs and outputs
encountered during interrupt processing.
➮ For KV-10/80 Series, see Chapter 6.
3.1 Interrupt Instructions ...................................................................... 3-192
3.2 Interrupt Processing ....................................................................... 3-194
3.2.1 Interrupt Processing ............................................................................... 3-194
3.2.2 Types of Interrupts ................................................................................. 3-195
3.2.3 Interrupt Priority ...................................................................................... 3-196
3.2.4 Interrupt Program ................................................................................... 3-196
3.3 Direct Input/Output .......................................................................... 3-197
3.3.1 Direct Input ............................................................................................. 3-197
3.3.2 Direct Output .......................................................................................... 3-197
3.4 Applications of Interrupt Programs ............................................ 3-198
3.4.1 Interrupt with a Signal Converter ............................................................ 3-198
3.4.2 Interrupt with a High-speed Counter ...................................................... 3-199
3.4.3 Measuring the ON Time of High-speed Pulses ...................................... 3-200
3.4.4 Measuring the Period in which a Target Passes between
Two Points ............................................................................................. 3-201
