4 Database
tiamo 2.4 (for Process Analysis)
￭￭￭￭￭￭￭￭ 243
Insert
In order to insert group field into a report template the corresponding
symbol must be selected on the Module bar and placed on the report
template by creating a field with the left-hand mouse key.
Properties
X pos.
Shows the predefined x-position for the field.
Y pos.
y-position within the permitted section.
Input range 0.0000 - (max. page height) mm
Width
Shows the predefined width of the fixed report.
Height
Height of the field
Input range 0.0000 - (max. page height) mm
4.4.1.4.3.9 Report template - Image
Program window: Database ▶ Report template
An image field is used for including any external graphics on the report
template. The file formats *.jpg and *.gif are supported.
Insert
In order to insert an image into a report template the corresponding sym-
bol must be selected on the Module bar and placed on the report tem-
plate by creating a field with the left-hand mouse key.
Properties
X pos.
x-position within the permitted section.
Input range 0.0000 - (max. page width) mm
Y pos.
y-position within the permitted section.
