7.6 846 Dosing Interface
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
1530 ￭￭￭￭￭￭￭￭
tiamo 2.4 (for Process Analysis)
Display message
A message is displayed and you can select whether you want to con-
tinue the sequence or cancel it. If the sequence is continued then the
message that the validity period has expired will be automatically saved
with the determination.
Cancel determination
The running determination will be automatically canceled. The follow-
ing message must be confirmed with [OK].
7.6 846 Dosing Interface
7.6.1 846 Dosing Interface - Overview
Dialog window: Configuration ▶ Devices ▶ [Edit] ▶ Properties… ▶ Properties - 'De-
vice type' - 'Device name'
The parameters for the 846 Dosing Interface are set on the following
tabs:
￭ General
General device information such as device name, device type, serial
number, etc.
￭ (see Chapter 7.1.5, page 1496)
Properties of the MSB connector and the peripheral devices connected
to it.
￭ GLP
Information on GLP tests and GLP monitoring.
7.6.2 Properties - General
Tab: Configuration ▶ Devices ▶ [Edit] ▶ Properties... ▶ Properties - 'Device type' -
'Device name' ▶ General
On the tab General, general properties of the device are displayed.
Device name
Designation of the device (can be freely defined by user).
Entry 50 characters
Default value Device type number_#
Device type
Display of the device type.
Program version
Shows the program version of the device.
Only visible with devices that have their own firmware.
