7.20 IO controller
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
1626 ￭￭￭￭￭￭￭￭
tiamo 2.4 (for Process Analysis)
Parameter 1
The meaning of Parameter 1 depends on the Type set.
Parameter 2
The meaning of Parameter 2 depends on the Type set.
[Edit]
Opens the dialog Properties Digital output in order to edit the selected
port.
[Port description]
Opens a menu in order to import or export port descriptions.
The menu [Port description] contains the following menu items:
Import Import of a text file (TXT, CSV) containing the port description. Each line is inter-
preted as port description, spaces will be ignored.
Export Export a text file containing the port descriptions of all digital inputs.
7.20.5.1 Properties Digital output
Dialogfenster Configuration ▶ Devices ▶ [Edit] ▶ Properties... ▶ Properties - 'De-
vice type' - 'Device name' ▶ Digital Outputs ▶ [Edit] ▶ Properties digital output
In the dialog window Properties Digital output the properties of the
individual digital outputs are set.
Port
Display of the internal designation for a digital output port of the type
DigOut_x_y_z, where x stands for the controller; y for the digital output
terminal and z for the output on this terminal.
Port description
Freely selectable designation for a digital output port. This designation is
used in the program to actuate the port.
Entry 50 characters
Default value DigOut_x_y_z
The following characters must not be part of the
port description: \ , ', ., {, }, [, ].
Port specification
Shows the specifications of the port.
Type
Selection of the port type.
