7.21 Stepping Motor Controller
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
1656 ￭￭￭￭￭￭￭￭
tiamo 2.4 (for Process Analysis)
7.21.4 Properties - Digital inputs
Tab: Configuration ▶ Devices ▶ [Edit] ▶ Properties... ▶ Properties - 'Device type' -
'Device name' ▶ Digital inputs
All recognized inputs are automatically listed in a table on the Digital
inputs tab. The port designation can be changed for each digital input.
Port
Display of the internal description of the port.
Port description
Display of the port description.
Port specification
Shows the port specification.
Type
Display of the port type.
Delayed edge
Indication of the edge type, i.e. rising or falling.
Delay time
Time that has to elapse before the input signal on the rising or falling
edge is recorded.
Invert signal
If this check box is activated, then the evaluation of the input signal is
inverted.
[Edit]
Opens the Properties Digital input dialog in order to edit the selected
port.
[Port description]
Opens a menu in order to import or export port designations.
The [Port description] menu contains the following menu items:
Import Import of a text file (*.txt; *.csv) containing the port designations. Each line is
interpreted as a port designation, empty lines will be ignored.
Export Export of a text file containing the port designations of all digital inputs.
