7 Devices
tiamo 2.4 (for Process Analysis)
￭￭￭￭￭￭￭￭ 1663
For Type = Stirrer:
￭ 0: Duration of the switch-on pulse fixed at 500 ms.
￭ >0: For 100% stirrer output (Parameter 1 = 100), pulse duration in
10 ms
Example:
Parameter 1 = 100, Parameter 2 = 30: Pulse duration switched-on
300 ms, switched off 0 ms
Parameter 1 = 75, Parameter 2 = 30: Pulse duration switched-on
225 ms, switched off 75 ms
Input range -214783647 - 214783647
Default value 0
7.21.6 Properties - Stepping motors
On the tab Stepping motors all stepping motors detected are automati-
cally listed. The parameters for each stepping motor can be set.
Port
Display of the internal description of the port.
Port description
Display of the port description.
Type
Display of the port type.
Action
Display of the stepping motor action.
Distance/Angle
The meaning of the parameter depends on the Action set.
[Edit]
Opens the dialog Properties Stepping motor in order to edit the
selected port.
[Port description]
Opens a menu in order to import or export port descriptions.
The menu [Port description] contains the following menu items:
Import Import of a text file (TXT, CSV) containing the port description. Each line is inter-
preted as port description, spaces will be ignored.
Export Export a text file containing the port descriptions of all digital inputs.
