7 Devices
tiamo 2.4 (for Process Analysis)
￭￭￭￭￭￭￭￭ 1535
7.7 814/815 USB Sample Processor
7.7.1 814/815 USB Sample Processor - Overview
Dialog window: Configuration ▶ Devices ▶ [Edit] ▶ Properties... ▶ Properties - 'De-
vice type' - 'Device name'
The parameters for the 814 USB Sample Processor and 815 Robotic
USB Sample Processor XL are set on the following tabs:
￭ General
General device information such as device name, device type, serial
number, etc.
￭ Tower #
Properties of tower 1 and tower 2 (if present).
￭ Rack
Information on the rack attached.
￭ Initializing position
Defining a position which is automatically approached when the sam-
ple changer is initialized.
￭ MSB #
Properties of the MSB connector 1 - 3 and the peripheral devices con-
nected to it.
￭ GLP
Information on GLP tests and GLP monitoring.
7.7.2 Properties - General
Tab: Configuration ▶ Devices ▶ [Edit] ▶ Properties... ▶ Properties - 'Device type' -
'Device name' ▶ General
On the tab General, general properties of the device are displayed.
Device name
Designation of the device (can be freely defined by user).
Entry 50 characters
Default value Device type number_#
Device type
Display of the device type.
Program version
Shows the program version of the device.
Only visible with devices that have their own firmware.
