6 Configuration
tiamo 2.4 (for Process Analysis)
￭￭￭￭￭￭￭￭ 1361
NOTE
For your own calibration buffers you should enter the pH values for the
temperature range in which your pH calibration and pH measurement
will later be carried out. If you do not know the pH values at individual
temperatures, they will be calculated automatically by linear interpola-
tion.
6.3.3.2 Templates - Input lines
6.3.3.2.1 Managing templates for input lines
Dialog window: Configuration ▶ Tools ▶ Templates ▶ Input lines ▶ Templates for
input lines
In the dialog window Templates for input lines, client-specific bit pat-
terns for scanning remote input signals can be defined which can be
selected with the command SCAN and in Manual Control. The table with
the defined templates cannot be edited, although it can be sorted accord-
ing to the selected column in increasing or decreasing sequence by click-
ing on the column title
[New]
Create a new template (see Chapter 6.3.3.2.2, page 1361).
[Edit]
Edit the selected template (see Chapter 6.3.3.2.2, page 1361).
[Delete]
Delete the selected template.
6.3.3.2.2 Editing templates for input lines
Dialog window: Configuration ▶ Tools ▶ Templates ▶ Input lines ▶ Templates for
input lines ▶ [New] / [Edit] ▶ New template / Edit template
With [New] or [Edit] the dialog window New template or Edit tem-
plate opens for entering a new template or for editing an existing tem-
plate.
Signal name
Name of the pattern for the input signal.
Entry 25 characters
Input signal
Entry of the bit pattern for the input signal with exactly 8 characters. It is
possible to enter the characters
0 = Line inactive,
