7.20 IO controller
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
1628 ￭￭￭￭￭￭￭￭
tiamo 2.4 (for Process Analysis)
Parameter 2
The meaning of Parameter 2 depends on the Type of the digital output
that has been set.
For Type = Stirrer:
￭ 0: Duration of the switch-on pulse fixed at 500 ms.
￭ >0: For 100% stirrer output (Parameter 1 = 100), pulse duration in
10 ms
Example:
Parameter 1 = 100, Parameter 2 = 30: Pulse duration switched-on
300 ms, switched off 0 ms
Parameter 1 = 75, Parameter 2 = 30: Pulse duration switched-on
225 ms, switched off 75 ms
Input range -214783647 - 214783647
Default value 0
7.20.6 Properties - Analog inputs
On the tab Analog inputs all inputs detected are automatically listed in a
table. For each analog input the settings can be modified.
Port
Display of the internal description of the port.
Port description
Display of the port description.
Type
Display of the port type.
Low level (0%)
Display of the lowest analog input value with unit.
High level (100%)
Display of the highest analog input value with unit.
0% Mapping
Measured value to be used when the Low level (0%) is applied as input
value, with unit.
100% Mapping
Measured value to be used when the High level (100%) is applied as
input value, with unit.
