Accessories (overview)
Filters
Mains filters for power supply modules
9

504 EDS94SPP101 EN 7.1
Rated data
Basis of the data
Mains
Voltage Voltage range Frequency range
U
LN
[V] U
LN
[V] f [Hz]
3/PE AC 230 180 - 0 % ... 264 + 0 % 45 ... 65
3/PE AC 400 320 - 0 % ... 440 + 0 % 45 ... 65
3/PE AC 500 400 - 0 % ... 550 + 0 % 45 ... 65
Voltage Freq. Current [A] Current [A] Number of
phases
[V] [Hz] c max. +45° C c max. +55° C
E94AZMP0084 230/400/500 50/60 8/8/8 6/6/6 3
E94AZMP0294 230/400/500 50/60 29/29/29 21.8/21.8/21.8 3
E94AZMP0824 230/400/500 50/60 82/82/82 61/61/61 3
E94AZMP2004 230/400/500 50/60 200/200/200 150/150/150 3
c Temperature in the control cabinet
Power loss Inductance Voltage drop
P
loss
[W] L [mH] Δ U [V]
E94AZMP0084 50 3.9 9.8
E94AZMP0294 110 0.7 6.4
E94AZMP0824 200 0.25 6.4
E94AZMP2004 350 0.10 6.3
Thermal contact
Design max. switching voltage max. switching current
U
Th
[V AC] I
Th
[A]
E94AZMP0084
NC contact, 150 °C 250 2.5
E94AZMP0294
E94AZMP0824
NC contact, 150 °C 250 2.5
E94AZMP2004
Fan
Voltage Current
[V DC] [A]
E94AZMP0824
24 0.3
E94AZMP2004
