Page 50: Device size 7
Single-axis controllers
Rated data (devices for 400/500V mains)
Operation at rated mains voltage 230 V
4
50
EDS94SPP101 EN 7.1
4.3.2
Operation at rated mains voltage 230 V
Device size 1 ... 6
Basis of the data
Mains
Voltage
Voltage range
Frequency range
U
LN
[V]
U
LN
[V]
f [Hz]
3/PE AC
230
180 - 0 % ... 264 + 0 %
45 - 0 % ... 65 + 0 %
2/PE DC
325
260 - 0 % ... 370 + 0 %
-
Mains current at I
aN
Output power
Motor power
(typical)
with external
mains choke
without external
mains choke
U, V, W
4 pol. ASM
Type
I
LN
[A]
I
LN
[A]
S
aN
[kVA]
P
aN
[kW]
P
aN
[hp]
E94ASxE0024
1.5
2.1
0.5
0.18
0.25
E94ASxE0034
2.5
3.5
0.9
0.37
0.5
E94ASxE0044
3.9
5.5
1.4
0.75
1
E94ASxE0074
7.0
9.9
2.5
1.5
2
E94ASxE0134
12.0
16.8
4.7
3
4
E94ASxE0174
15.0
21.0
5.9
4
5.5
E94ASxE0244
20.5
29.0
8.4
5.5
7.5
E94ASxE0324
-
29.0
11.5
7.5
10
E94ASxE0474
-
43.0
16.9
11
15
E94ASxE0594
-
54.0
21.2
15
20
Device size 7
Basis of the data
Mains
Voltage
Voltage range
Frequency range
U
LN
[V]
U
LN
[V]
f [Hz]
3/PE AC
230
180 - 0 % ... 264 + 0 %
45 - 0 % ... 65 + 0 %
Mains current at I
aN
Output power
Motor power
(typical)
with external
mains choke
without external
mains choke
U, V, W
4 pol. ASM
Type
I
LN
[A]
I
LN
[A]
S
aN
[kVA]
P
aN
[kW]
P
aN
[hp]
E94ASxE0864
-
79.0
30.8
22
29
E94ASxE1044
-
95.0
37.3
30
40
