Cygnus 2 Operating Manual
1.5 Unpacking and Inspection
1 If the Cygnus 2 has not been removed from its shipping container, do so now.
2 Carefully examine the Cygnus 2 for damage that may have occurred during
shipping. This is especially important if you notice obvious rough handling on
the outside of the container. Immediately report any damage to the carrier and
to INFICON.
3 Do not discard the packing materials until you have taken inventory and have
at least performed a power on verification.
4 Take an inventory of your order by referring to your order invoice and the
information contained in
section 1.6 on page 1-17 .
5 To perform a power-on verification, see section 1.7 on page 1-19 .
6 For additional information or technical assistance, contact INFICON, refer to
section 1.3, How To Contact INFICON, on page 1-6 .
1.6 Parts and Options Overview
1.6.1 Base Configurations
Cygnus 2 Control Unit . . . . . . . . . . . 781-500-G11 North America,
781-500-G12 Europe
Ship Kit . . . . . . . . . . . . . . . . . . . . . . . 781-020-G1 North America,
781-020-G2 Europe
Operating Manual on CD ROM . . . . 074-545 on 074-5000-G1 CD ROM included
in Ship Kit
I/O Relay . . . . . . . . . . . . . . . . . . . . . Contains Input/Relay Interface Connectors
(8 relay outputs, 14 TTL inputs). Included in
Ship Kit.
1.6.2 Pre-installed Options or Spares
Additional Sensor Module . . . . . . . . 781-132-G1 (up to 2 extra)
The following contain board and interface connector
I/O Relay Card . . . . . . . . . . . . . . . . . 781-502-G1
(8 relay outputs, 14 TTL inputs)
781-503-G1
(8 relay outputs, 14 TTL outputs)
DAC Option Board and Kit . . . . . . . . 781-504-G1
Ethernet . . . . . . . . . . . . . . . . . . . . . . 781-102-G2
