Cygnus 2 Operating Manual
13.2 User Messages
Table 13-2 messages are a subgroup of status messages. The user defines these
messages. They are displayed and cleared via logic actions. The messages will
display in the same screen area as other status messages.
Table 13-2 User messages
Status Message Set Cleared Screen Remote Comm. Encode
User Message 1 Logic event “Message On 1” Logic event “Message Off 1” All 0x0000,0000,0000,0200
User Message 2 Logic event “Message On 2” Logic event “Message Off 2” All 0x0000,0000,0000,0100
User Message 3 Logic event “Message On 3” Logic event “Message Off 3” All 0x0000,0000,0000,0080
User Message 4 Logic event “Message On 4” Logic event “Message Off 4” All 0x0000,0000,0000,0040
User Message 5 Logic event “Message On 5” Logic event “Message Off 5” All 0x0000,0000,0000,0020
User Message 6 Logic event “Message On 6” Logic event “Message Off 6” All 0x0000,0000,0000,0010
User Message 7 Logic event “Message On 7” Logic event “Message Off 7” All 0x0000,0000,0000,0008
User Message 8 Logic event “Message On 8” Logic event “Message Off 8” All 0x0000,0000,0000,0004
User Message 9 Logic event “Message On 9” Logic event “Message Off 9” All 0x0000,0000,0000,0002
User Message 10 Logic event “Message On 10” Logic event “Message Off 10” All 0x0000,0000,0000,0001
