Cygnus 2 Operating Manual
9.4.28 Status General
Command = SG
Command ID = See "Description" in Table 9-12 .
Option = |< Integer > | <32 Bit Word> | <48 Bit Word>
Response = … | …
Table 9-12 Status general commands
SG
Comm
and ID Description Option
Number
of bytes
in the
response
Data Returned Notes
0
(0x00)
N/A
3
(0x03)
Output status 5
Each bit
represents an output,
bit set means output
active.
MSB of first byte is
output 1.MSB of the
fifth byte is output 33.
4
(0x04)
Input status 4
Each bit
represents an input. Bit
set means input active.
MSB of first byte is
input 1. MSB of the
fourth byte is input 25.
5
(0x05)
Logic statement
status
13
Each bit
represents a logic
statement, bit set
means logic statement
is true.
MSB of first byte is logic
statement 1.MSB of the
thirteenth byte is logic
statement 97.
6
(0x06)
Status Messages 8 See encodes in section
13.1 on page 13-1 . One
bit is set for each error.
Multiple bits may be
set.
