Cygnus 2 Operating Manual
9.4.27 Cygnus 2 Action List
Actions are triggered in the Logic Statement THEN section. Logic codes are used
in the remote communication query and update commands. Some actions that
require a numeric may act on all items by entering a zero, as noted in
Table 9-11 .
Table 9-11 Action list
Actions Numeric
(Byte)
Min Max Logic
Code
Extern Out On XXX
Output # 1 38
0x41
Extern Out Off XXX 0x42
Not Used
Material # 0 6
0x43
Not Used 0x44
Start XXX 0x45
Reset XXX 0x46
Stop XXX 0x47
Zero Deposit Time XXX 0x48
Zero Thick XXX 0x49
Trig Fnl Thick XXX 0x4A
Continue Dep XXX 0X4B
Start Deposit XXX 0x4C
Go to NonDep XXX 0x4D
Go to PostDep XXX 0x4E
Increment Count XXX
Counter # 1 20
0x4F
Clear Counter XXX 0x50
Start Timer XXX
Timer # 1 20
0x51
Cancel Timer XXX 0x52
Switch Xtal XXX Sensor # 1 6 0x53
