Cygnus 2 Operating Manual
Test 0x7D 0x83
Not Used 0x7E 0x82
Rate Dev(iation)
Err(or)
0x7F 0x81
Note 1: Seconds are entered via remote communications as tenths of seconds. Seconds
are entered by keyboard as whole numbers.
Note 2: The time is entered via remote communications as whole minutes. 99 hours =
5940 minutes, so 99 hours + 59 minutes = 5999 minutes maximum. The time entered by
keyboard is in hours and minutes.
Note 3: Maximum number of minutes is 59. The entry of '00:65' is invalid. That time can
be entered as '01:05'.
Note 4: Thick Sum will be sent as an integer Angstroms (the number multiplied by 1000).
Table 9-10 Event list (continued)
Events 1st
numeric
(1 Byte)
(XXX)
Min Max 2nd
numeric
(Integer)
(YYY)
Min Max Logic
Code
Logic
Code
Negated
