7. Utility Reference
299
7.5 The dlmchkpath Utility for Checking HDLM Paths
If you install or uninstall HDLM in a multi-path configuration, the disk might become
corrupted. Use the
dlmchkpath
utility to check HDLM paths and to make sure that
the system is in a single-path configuration. During an upgrade installation, a
re-installation, or uninstallation of HDLM, the
dlmchkpath
utility is executed
automatically. If the system is in a single-path configuration, the
dlmchkpath
utility
displays nothing during an upgrade installation, a re-installation, or uninstallation of
HDLM. A warning dialog box will appear if the system is in a multi-path
configuration.
However, when you use one of the following methods of installing HDLM and the
system is determined to be a multi-path configuration, the installation will terminate
without displaying any warning dialog boxes:
• Upgrade installation using the unattended installation
• Re-installation using the unattended installation
When the
dlmchkpath
utility is executed manually, a message will appear as shown
in the execution example in 7.5.2 Parameters. This utility is located in the following
location:
HDLM-installation-folder
\bin
7.5.1 Format
dlmchkpath {-singleconnect | -h}
7.5.2 Parameters
-singleconnect
Checks whether a single path configuration is being used to connect the HDLM
management-target LU to the host.
Examples
In the following example, the utility determines that the system is in a
single-path configuration:
>dlmchkpath -singleconnect
KAPL12401-I All LUs managed by HDLM are in a single path
configuration.
In the following example, the utility determines that the system is in a
multi-path configuration:
