Monitoring and Managing the Switch
95
Edge Switch Element Manager User Guide
Note:
The status indicator displays on the port in the Hardware View. It indicates that a
corrective action is required to return the port to a normal operating state.
Testing
Off
Blinking
Yellow
Triangle
Port is executing an internal loopback
test.
On
Blinking
Yellow
Triangle
Port is executing an external loopback
test.
Note: For any loopback test, the amber
LED blinks (beacons) to help users
locate the port under test.
Not
Installed
Off
Off
None
The port optics are not installed, or the
feature that provides additional port
function is not enabled.
Table 4: Port States and Indicators (Continued)
Port State
Green/Blue
Port
Indicator
Amber
Port
Indicator
Alert
Indicator
Description
