Using Logs
159 Edge Switch Element Manager User Guide
Threshold Alert Log
This log provides details of threshold alert notifications. Besides the date and time
that the alert occurred, the log also displays details about the alert, as configured
through the Threshold Alerts option under the Configure menu. To open the
Audit Log, click Logs > Threshold Alert Log.
Figure 56: Threshold Alert Log
■ Date/Time—Date and time stamp for when the alert occurred.
■ Name—Name for the alert, as configured through the Configure Threshold
Alerts dialog box.
■ Port—Port number where the alert occurred.
■ Type—The type of alert: transmit (Tx) or receive (Rx).
