Monitoring and Managing the Switch
60
Edge Switch Element Manager User Guide
Front View
1
Port Attention Indicator
The yellow triangle (
) on the port connector graphic indicates that a link
incident occurred or that the port is not operational, in nonstandard mode of
operation, or has other status. You can determine the reason for a link incident
by displaying the Port Properties dialog box for the port. For details on status
symbols, see
on page 93. For information on link incidents, see “
2
Port LED Indicator
The two round indicators (green or blue and amber) to the left of each port
connector simulate LED operation on the actual switch port. A green LED
indicates that the port is online with an operating speed of 1 gigabit per
second (Gbps). A blue LED indicates that the port is online with an operating
speed of 2 Gbps. When the amber indicator illuminates steadily, the port has
failed and requires service. For details on port LED indicator operation, see
on page 93.
3
Port Failure Indicator
A blinking red and yellow diamond ( ) over a port connector indicates that
the port has failed. See
on page 93 for details on port operating states
and the status symbol and indicator operation.
4
Beaconing
When a blinking amber LED indicator displays by a port and a yellow triangle
attention indicator ( ) displays over the port's connector, beaconing is
enabled. See
on page 93 for details on port operating states and the
status symbol and indicator operation.
5
Not Installed
The port optics are not installed, or the feature that provides additional port
function is not enabled.
