HP StorageWorks 2.12 Edge Switch - Manual (Page 146)

Configuring the Switch
146 Edge Switch Element Manager User Guide
To export a configuration report:
1. Click Configure > Export Configuration Report.
The Export Configuration Report dialog box displays.
Figure 50: Export Configuration dialog box
2. Click the folder where you want to save the file.
3. Type in a file name and extension in the File name field.
4. Click Save. The file saves to the specified folder as an ASCII text file.
Enabling Embedded Web Server
Use the following steps to enable EWS:
1. At the Hardware View page, click Configure > Enable Web Server.
Choosing Enable Web Server automatically places a check mark in the
check box.
2. Click Enable Web Server again to remove the check mark and disable the
EWS interface. When disabled, remote users cannot access the interface.
For complete procedures on using EWS, refer to HP StorageWorks Embedded
Web Server User Guide.
1
Details
2
List
3
Create new folder
4
Home
5
Go up one level
6
Drive list
1
2
3
4
5
6
