Configuring the Switch
114
Edge Switch Element Manager User Guide
Figure 30: Specifying Preferred Path for Switch 2
The following rules apply when configuring Preferred Paths:
■
The switch’s domain ID must be set to Insistent.
■
Domain IDs must be in the range of 1 through 31.
■
The specified numbers for Source Ports and Exit Ports must be in the range
equal to the number of ports for the switch being configured.
■
For any source port, only one path may be defined to each destination
domain ID.
To install and enable the Preferred Path option, click Configure > Features. See
“
” on page 131 for more information.
