Element Manager Overview

27

Edge Switch Element Manager User Guide

Figure 3: Element Manager window (Hardware View for the Edge Switch 2/24)

Note:

The HAFM window is still available as a separate window. You can drag the

Element Manager window away from the other window and view both windows on

your desktop, or you can minimize one or both of them to icons, if desired. You can

have a maximum of four Element Manager windows open concurrently.

Opening the Online Help

Use the following steps to open the online help:

1. Open the Element Manager for the switch from the HAFM desktop, as

described in “

Opening the Element Manager

” on page 26.

2. Click Help > Contents or press F1.

Status bar

View tabs

Menu bar

View panel
