Configuring the Switch
105 Edge Switch Element Manager User Guide
Configuring Fabric Parameters
The Configure Fabric Parameters dialog box enables you to configure the Fibre
Channel operating parameters.
To set fabric parameters:
Note: The switch must be offline to change parameters in this dialog box. If it is not
and you activate values in this dialog box, a dialog box displays, prompting you to set
the unit offline.
Caution: Setting the switch offline terminates all Fibre Channel connections.
1. Set the unit offline:
a. Click Maintenance > Set Online State. The Set Online State dialog box
displays.
b. Click Set Offline. A warning box displays asking you to confirm the
offline state.
c. Click OK.
2. Click Configure > Operating Parameters > Fabric Parameters. The
Configure Fabric Parameters dialog box displays.
Figure 26: Configure Fabric Parameters dialog box (Edge Switch 2/32)
Note: Ordinarily, you do not need to change values in this dialog box from their
defaults. Change the values if the switch will participate in a multiswitch fabric.
