Element Manager Overview
30
Edge Switch Element Manager User Guide
Configure Menu
Click Configure on the menu bar to display a menu that lists the following
options. For detailed information on using these options, see “
Identification
Click this option to display the Configure Identification dialog box. Enter the
following information in this dialog box:
■
Name—Enter a product name. Note that you can set this name as the
nickname for the switch’s WWN, using the Set Name as Nickname check
box. The nickname then displays instead of the WWN in Element Manager
views.
Note:
You can configure a maximum of 2,048 nicknames.
■
Description—Enter a unique product description.
■
Location—Enter the product’s location.
■
Contact—Enter a contact either by name, phone number, or e-mail address.
Note:
This information displays in the identification table at the top of the Hardware
View and in the HAFM Physical/Topology Map, if the view is configured to display
names.
Operating Parameters
This option lets you configure switch and fabric parameters, as follows:
■
Click Switch Parameters to display the Configure Switch Parameters dialog
box, which allows you to set Fibre Channel operating parameters. Using this
dialog box, you can set parameters, such as preferred domain ID
(1 through 31), Domain RSCNs, and Suppress RSCNs on Zone Set
Activations. In addition, you can also enable the rerouting delay feature. See
“
Configuring Operating Parameters
” on page 101 for more information.
