GSP-830 User Manual
70
Search next highest peak
The marker keeps moving to the next highest peak, in descending order.
Panel operation 1. Press the Peak Search key.
Peak Search
2. Press F2 to F4 repeatedly.
Next Peak moves the marker
to the next highest peak.
Next Pk Right moves the
marker to the next highest
peak on the right side (higher
frequency).
Next Pk Left moves the
marker to the next highest
peak on the left side (lower
frequency)
Next Peak F 2
Next Pk
Right
F 3
Next Pk
Left
F 4
Display
F2
F4 F3
Search highest peak and move to center
Method 1 1. Press the Peak Search key.
Peak Search
2. Press F1 (Pk Search).
Mkr Center F 5
Method 2 1. Make sure that the marker is
already activated. If not, press
the Marker key.
Marker
2. Press F4 (To Peak).
To Peak F 4
3. Press F5 (Mkr→Center).
Mkr Center F 5
