GSP-830 User Manual
164
meas:mark:tocen Moves a normal/delta marker to the center frequency.
Parameter: 1 to 5 (marker ID)
Example: meas:mark:tocen_1 (marker 1 to the center freq)
meas:mark:tost Moves a normal/delta marker to the start frequency.
Parameter: 1 to 5 (marker ID)
Example: meas:mark:tost_1 (marker 1 to the start frequency)
meas:mark:tostp Moves a normal/delta marker to the stop frequency.
Parameter: 1 to 5 (marker ID)
Example: meas:mark:tostp_1 (marker 1 to stop frequency)
meas:mark:toss Moves a normal/delta marker to the center frequency + step.
Parameter: 1 to 5 (marker ID)
Example: meas:mark:toss_1 (marker 1 to center freq + step)
meas:mark:torefl Moves a normal/delta marker to the reference level.
Parameter: 1 to 5 (marker ID)
Example: meas:mark:torefl_1 (marker 1 to the reference level)
meas:mark:trace Moves a normal/delta marker to a trace.
Parameter: 1 to 5 (marker ID), followed by 0 (auto), 1
(traceA), 2 (traceB), 3 (traceC)
Example: meas:mark:trace_1_2 (marker 1 to traceB)
meas:mark:marktable:on Activates marker table.
meas:mark:marktable:off Deactivates marker table.
meas:mark:peaktable:on Activates peak table.
meas:mark:peaktable:off Deactivates peak table.
meas:mark:peaktable:sortf Sorts peak table by frequency.
meas:mark:peaktable:sorta Sorts peak table by amplitude.
meas:mark:peaktrack:on
Turns On peak track. Parameter: 1 to 5 (marker ID)
Example: meas:mark:peaktrack:on_1(marker1 track on)
meas:mark:peaktrack:off Turns Off peak track. Parameter: 1 to 5 (marker ID)
Example: meas:mark:peaktrack:off_1(marker1 track off)
meas:mark:peakthres:on Turns On peak threshold and sets amplitude.
Parameter: peak threshold in dB. Example:
meas:mark:peakthres:on_−30 (−30dB threshold)
meas:mark:peakthres:off Turns Off peak threshold.
Trace
meas:tra Sets the mode for a trace. Parameter: 1 (traceA), 2 (traceB), 3
(traceC), followed by 1(clear), 2(peak hold), 3(view), 4(blank)
Example: meas:tra_1_2 (traceA set to peak hold mode)
meas:tra:avg:on Turns On average mode and sets average number for a trace.
Parameter: 1(traceA), 2(traceB), 3(traceC), followed by No.
Example: meas:tra:avg:on_1_20 (Average trace A 20 times)
meas:tra:avg:off Turns Off the average mode.
Parameter: 1 (traceA), 2 (traceB), 3 (traceC)
Example: meas:tra:avg:off_1 (traceA average mode Off)
