EMI FILTER
147
Select 9kHz/120kHz RBW
Panel operation 1. Press the BW key.
BW
2. Press F1 (RBW Man).
RBW
Auto Man
F 1
3. Select 9kHz/120kHz RBW
using the Arrow keys or Scroll
knob. The RBW value appears
in the command window.
RBW: 9kHz
Note In the automatic mode, RBW is selected according to the
internal reference setting.
For reference RBW/VBW setting, see page99.
Check EMI filter installation status
Panel operation 1. Press the System key.
System
2. Press F6 (More).
More... F 6
3. Press F4 (System Config On).
The system configuration
window appears.
System Config
On Off
F 4
4. The 9/120k RBW sign shows
the installation status, installed
(checked) or not installed
(unchecked).
Installed
Not installed
Note EMI filter (9k/120k RBW) and 10k/100k RBW are
exclusive. These two optional items cannot be installed
together.
