background image

SYSTEM

131

View self-test result

Background

The GSP-830 runs a series of internal tests upon
power-up. If any of the test result shows Fail, contact
the service center.

Panel operation

1. Press the System key.

System

2. Press F6 (More).

More...

F 6

3. Press F2 (Self Test).

Self Test...

F 2

4. The result appears in F1 to F4.

(The GPIB result appears only
when the module is installed)

GPIB

Pass Fail

F 1

Flash

Pass Fail

F 2

SDRAM

Pass Fail

F 3

RTC

Pass Fail

F 4

5. Press F6 (Return) to go back to

the previous menu.

Return

F 6

Item GPIB

The optional GPIB interface connection.
Available only when the GPIB module is
installed (page129).

Flash

Internal Flash memory area for storing
the system code and data.

SDRAM

Internal SDRAM area on which the code
runs.

RTC

The real-time clock that controls the date
and time settings (page132).
