PC SOFTWARE
153
2. Click the setting icon. The
parameter setting window appears.
3. Select the connection port (COM port).
To check the configuration in the PC, go to Control
panel → System properties → Device Manager.
5. Click the Setting icon again to close
the setting window
6. Click the Open COM Port icon. The
connection is established when the
other icons become active.
Functionality check Click the Capture icon. Make sure the
waveform shown in the GSP-830 display
is captured correctly.
