GSP-830 User Manual

168

con:trig:single

Sets the trigger condition to single.

con:trig:cont

Sets the trigger condition to continuous.

con:trig:ext

Sets the trigger to external mode.

con:trig:delay

Sets the trigger delay in msec.
Example: con:trig:delay_1000 (1000ms delay)

con:trig:freq

Sets the trigger frequency in MHz.
Example: con:trig:freq_1 (1MHz)

Display

con:disp:dim

Selects the display dimmer level. Parameter: 0 to 5
Example: con:disp:dim_2 (dimmer level 2)

con:disp:dl

Turns On/Off display line. Parameter: on, off
Example: con:disp:dl_on (display line On)

con:disp:dl:level

Sets the display line level in current unit.
Example: con:disp:dl:level_−50 (display line at −50dBm)

con:disp:title:show

Sets and shows the display title. The title is case sensitive.
Example: con:disp:title:show_SAtest (title is SAtest)

con:disp:title:clr

Clears the display title.

con:disp:split:upper Turns On and sweeps upper window in split window mode.
con:disp:split:lower

Turns On and sweeps lower window in split window mode.

con:disp:split:alt Sweeps

the

upper/lower window alternatively in split mode.

con:disp:split:full

Goes back to full screen mode.

File

con:file:copy

Copies file. Need to specify the source and destination file.
Parameter: ta/tb/tc (traceA/B/C), t1to10 (trace1to10), lh/ll
(high/low limit line), lh1to5 (high limit line 1to5), ll1to5 (low
limit line 1to5), c1to5 (correction set 1to5), q1to10 (sequence
1to10), s1to10 (setup 1to10), file name in USB flash drive
Example: con:file:copy_t10_ta (copy from trace10 to traceA)
Example: con:file:copy_ta_mytrace (copy from traceA to a file
in external USB flash named mytrace)

con:file:del

Deletes file. Need to specify the source and destination file.
Parameter: ta/tb/tc (traceA/B/C), t1to10 (trace1to10), lh/ll
(high/low limit line), lh1to5 (high limit line 1to5), ll1to5 (low
limit line 1to5), c1to5 (correction set 1to5), q1to10 (sequence
1to10), s1to10 (setup file 1to10), file name in external USB
flash drive. Example: con:file:del_t10 (delete trace10)
Example: con:file:del_myspace (delete a file names myspace
in extrenal USB flash drive)

con:file:prtsc:tofile

Saves the display image to external USB flash drive. Need to
specify the file name. Example: con:file:prtsc:tofile_myscreen
(saves the display image to a file named myscreen)
