Measurement
keys
Limit Line
Meas
Trace
Peak Search
Marker
Marker key (page62) activates markers
and places them on specified locations.
Peak Search key (page68) searches peak
signals and configures peak ranges/orders.
Trace key (page73) activates trace signals,
configures them, and runs trace math
operations.
Measurement key (page82) configures
and runs 4 types of Power Measurements:
ACPR, OCBW, N-dB, and Phase Jitter.
Limit Line key (page90) configures
high/low limit lines and runs the pass/fail
test.
Control keys
Display
BW
Trigger
File
BW key (page95) configures the
RBW/VBW width, sweep time length, and
waveform averaging number.
Trigger key (page103) selects the trigger
type, sets the trigger running mode / delay
/ frequency, and activates the external
trigger input.
Display key (page107) configures the
LCD dimmer, edits and shows the display
line and title, and activates split windows.
File key (page113) saves/recalls/deletes
the trace waveform, limit line, amplitude
correction, sequence, and panel settings.
Display images may be saved to a storage
device via the front panel USB port.
State Keys
Seq
Option
System
Preset
Preset key (page40or123) resets the
GSP-830 to a predefined state.
System key configures the date/time
(page132), GPIB/RS232C interface
(page126), and language (page135). It also
shows the system information (page128)
and self test result (page131), and
saves/recalls panel settings (page125).
Option key configures the Tracking
Generator (page142), Demodulator
(page144), battery (page148), and external
reference frequency (page133).
Seq key (page136) edits and runs
sequences (user-defined macro).
