GSP-830 User Manual

44

View Signal (Start and Stop)

Start-and-Stop method defines the beginning (start) and
the end (stop) of the frequency range.

Set frequency adjustment Step

Background

Frequency adjustment step defines
the Arrow keys resolution for
Center, Start, and Stop frequency.

Panel operation

1. Press the Frequency key.

Frequency

2. Press F4 (Step).

Step

0 kHz

F 4

3. Enter the value using the

Numerical and Unit keys,
Arrow keys, and Scroll knob.

BK SP

dB

Enter

GHz /

Sec

mSec

MHz /

kHz /

Sec

μ

Range

0.0kHz to 3.0GHz
* Arrow keys and Scroll knob resolution: 1/10 of span

Set start frequency

Panel operation

1. Press the Frequency key.

Frequency

2. Press F2 (Start).

Start

0 kHz

F 2

3. Enter the value using the

Numerical and Unit keys, Arrow
keys, and Scroll knob.

BK SP

dB

Enter

GHz /

Sec

mSec

MHz /

kHz /

Sec

μ

Range

0kHz to 3GHz (start frequency ≤ stop frequency)
Arrow keys and Scroll knob resolution: step value

Note

Center frequency and span settings automatically change
according to start and stop frequency settings, and vice
versa.
