GSP-830 User Manual
68
P
EAK SEARCH
The Peak search function automatically locates signal
peaks in various conditions, such as in next highest peak
and minimum peak. The Peak Search overlaps its feature
with the Marker function, and it is best to use the two
together. All peaks can be viewed at once using the peak
table, with configurable amplitude threshold and sorting
order.
Search Signal
Peaks Search signal peak ................................................. 69
Search next highest peak ....................................... 70
Search highest peak and move to center ............... 70
Search minimum amplitude .................................. 71
Show Peak Table Activate peak table................................................. 71
Set peak threshold ................................................. 72
Sort peak ............................................................... 72
