GSP-830 User Manual
66
Move marker and highest peak to center
Method 1 1. Check the active marker at the
top right corner of the display.
2. Press the Marker key.
Marker
3. Press F4 (To Peak). The marker
moves to the signal peak.
To Peak F 4
4. Press F5 (Mkr→Center). The
signal peak moves to the center.
Mkr Center F 5
Method 2 1. Alternatively, press the Peak
Search key.
Peak Search
2. Press F5 (Mkr→Center). The
signal peak moves to the peak,
then to the display center.
Mkr Center F 5
Move marker to various locations
Panel operation 1. Check the active marker at the
top right corner of the display.
2. Press the Marker key.
Marker
3. Press F6 (More).
More F 6
4. Press F4 (Mkr to...)
Mkr to... F 4
5. Select the destination and press
F1 (Center) to F5 (Ref Lvl).
Center: center frequency
Start: start frequency
Stop: stop frequency
CF Step: set the marker
frequency as the frequency step
value
Ref Lvl: reference amplitude
level
Mkr Center F 1
Mkr Start F 2
Mkr Stop F 3
Mkr CFStep F 4
Mkr Ref Lvl F 5
6. Press F6 (Return) to go back to
the previous menu.
Return F 6
