REMOTE CONTROL
163
meas:autoset:amp:mode? Returns the autoset amplitude floor setting mode.
Parameter: auto, manual
meas:autoset:span:auto Sets the autoset frequency span setting to auto mode.
meas:autoset:span:man Sets the autoset frequency span setting to manual mode.
Need to specify unit. Example:
meas:autoset:span:man_100_khz (100kHz)
meas:autoset:span:mode? Returns the autoset frequency span setting mode.
Parameter: auto, manual
Marker & Peak Search
meas:mark:on? Returns marker On/Off. Need to specify the marker ID.
Parameter: on, off Example: meas:mark:on_1? (marker1 On?)
meas:mark:on Turn On marker. Parameter: 1to5 (marker ID), all (all
markers) Example: meas:mark:on_1 (marker 1 On)
meas:mark:off Turn Off marker. Parameter: 1 to 5 (marker ID), all (all
markers) Example: meas:mark:off_1 (marker 1 Off)
meas:mark:norm Sets a marker to normal mode. Parameter: 1 to 5 (marker ID)
Example: meas:mark:norm_1 (marker 1 normal mode)
meas:mark:norm:
freq? Returns the frequency of a normal marker. Need to specify ID.
Example: meas:mark:norm:freq_1? (normal mkr1 frequency?)
meas:mark:norm:
level? Returns the amplitude of a normal marker. Need to specify
ID. Example: meas:mark:norm:level_1? (normal mkr1 level?)
meas:mark:delta Sets a marker to delta mode. Also sets the relative frequency.
Parameter: 1 to 5 (marker ID)
Example: meas:mark:delta_1 (marker 1 in delta mode)
Example: meas:mark:delta_1_10_mhz (marker 1 in delta
mode, relative frequency 10MHz)
meas:mark:delta:freq? Returns the relative frequency of a delta mkr. Need to specify
ID. Example: meas:mark:delta:freq_1?(delta mkr1 freq?)
meas:mark:delta:
level? Returns the relative amplitude of a delta mkr. Need to specify
ID.Example: meas:mark:delta:level_1?(delta mkr1 amp?)
meas:mark:tomin Moves a marker to minimum peak. Parameter: 1 to 5 (marker
ID) Example: meas:mark:tomin_1 (marker 1 to min peak)
meas:mark:topeak Moves a marker to the peak. Parameter: 1 to 5 (marker ID)
Example: meas:mark:topeak_1 (marker 1 to peak)
meas:mark:tonp Moves a normal/delta marker to the next peak.
Parameter: 1 to 5 (marker ID)
Example: meas:mark:tonp_1 (marker 1 to the next peak)
meas:mark:tonpr Moves a normal/delta marker to the next right peak.
Parameter: 1 to 5 (marker ID)
Example: meas:mark:tonpr_1 (marker 1 to the next right pk)
meas:mark:tonpl Moves a normal/delta marker to the next left peak.
Parameter: 1 to 5 (marker ID)
Example: meas:mark:tonpl_1 (marker 1 to the next left peak)
