ATmega329/3210/649/6410
2552H–AVR–11/06
Table 34. Overriding Signals for Alternate Functions in PC7:PC4
Signal
Name
PC7/SEG5 PC6/SEG6 PC5/SEG(11/7) PC4/SEG(12/8)
PUOE LCDEN LCDEN LCDEN LCDEN
PUOV 0 0 0 0
DDOE LCDEN LCDEN LCDEN LCDEN
DDOV 0 0 0 0
PVOE 0 0 0 0
PVOV 0 0 0 0
PTOE – – – –
DIEOE LCDEN LCDEN LCDEN LCDEN
DIEOV 0 0 0 0
DI – – – –
AIO LCDSEG LCDSEG LCDSEG LCDSEG
Table 35. Overriding Signals for Alternate Functions in PC3:PC0
Signal
Name
PC3/SEG(13/9) PC2/SEG(14/10) PC1/SEG(15/11) PC0/SEG(16/12)
PUOE LCDEN LCDEN LCDEN LCDEN
PUOV 0 0 0 0
DDOE LCDEN LCDEN LCDEN LCDEN
DDOV 0 0 0 0
PVOE 0 0 0 0
PVOV 0 0 0 0
PTOE – – – –
DIEOE LCDEN LCDEN LCDEN LCDEN
DIEOV 0 0 0 0
DI – – – –
AIO LCDSEG LCDSEG LCDSEG LCDSEG
