261
ATmega329/3290/649/6490
2552H–AVR–11/06
Table 114. ATmega3290/6490 Boundary-scan Order, 100-pin
Bit Number Signal Name Module
242 AC_IDLE Comparator
241 ACO
240 ACME
239 AINBG
238 COMP ADC
237 ACLK
236 ACTEN
235 PRIVATE_SIGNAL1 (1)
234 ADCBGEN
233 ADCEN
232 AMPEN
231 DAC_9
230 DAC_8
229 DAC_7
228 DAC_6
227 DAC_5
226 DAC_4
225 DAC_3
224 DAC_2
223 DAC_1
222 DAC_0
221 EXTCH
220 GNDEN
219 HOLD
218 IREFEN
217 MUXEN_7
216 MUXEN_6
215 MUXEN_5
214 MUXEN_4
213 MUXEN_3
212 MUXEN_2
211 MUXEN_1
210 MUXEN_0
209 NEGSEL_2
208 NEGSEL_1
