167
ATmega329/3290/649/6490
2552H–AVR–11/06
Note: 1. See “About Code Examples” on page 8.
More advanced initialization routines can be made that include frame format as parame-
ters, disable interrupts and so on. However, many applications use a fixed setting of the
baud and control registers, and for these types of applications the initialization code can
be placed directly in the main routine, or be combined with initialization code for other
I/O modules.
Assembly Code Example (1)
USART_Init:
; Set baud rate
out UBRR0H, r17
out UBRR0L, r16
; Enable receiver and transmitter
ldi r16, (1<
out UCSR0B,r16
; Set frame format: 8data, 2stop bit
ldi r16, (1<
out UCSR0C,r16
ret
C Code Example (1)
#define FOSC 1843200 // Clock Speed
#define BAUD 9600
#define MYUBRR FOSC/16/BAUD-1
void main( void )
{
...
USART_Init(MYUBRR)
...
}
void USART_Init( unsigned int ubrr)
{
/* Set baud rate */
UBRR0H = (unsigned char)(ubrr>>8);
UBRR0L = (unsigned char)ubrr;
/* Enable receiver and transmitter */
UCSR0B = (1<
/* Set frame format: 8data, 2stop bit */
UCSR0C = (1<
}
