348
ATmega329/3290/649/6490
2552H–AVR–11/06
Figure 196. Programming Current vs. V
CC
Current Consumption in
Reset and Reset Pulsewidth Figure 197. Reset Supply Current vs. V
CC
(0.1 - 1.0 MHz, Excluding Current Through
The Reset Pull-up)
PROGRAMMING CURRENT vs. V
cc
85 ˚C
25 ˚C
-40 ˚C
0
2
4
6
8
10
12
14
16
18
20
1.5 2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I CC
(mA)
RESET SUPPLY CURRENT vs. V
CC
0.1 - 1.0 MHz, EXCLUDING CURRENT THROUGH THE RESET PULLUP
5.5 V
5.0 V
4.5 V
4.0 V
3.3 V
2.7 V
1.8 V
0
0.02
0.04
0.06
0.08
0.1
0.12
0.14
0.16
0.18
0.2
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
Frequency (MHz)
I CC
(mA)
