ATmega329/3290/649/6490
2552H–AVR–11/06
169 MUXEN_4
168 MUXEN_3
167 MUXEN_2
166 MUXEN_1
165 MUXEN_0
164 NEGSEL_2
163 NEGSEL_1
162 NEGSEL_0
161 PASSEN
160 PRECH
159 ST
158 VCCREN
157 PE0.Data Port E
156 PE0.Control
155 PE0.Pull-up_Enable
154 PE1.Data
153 PE1.Control
152 PE1.Pull-up_Enable
151 PE2.Data
150 PE2.Control
149 PE2.Pull-up_Enable
148 PE3.Data
147 PE3.Control
146 PE3.Pull-up_Enable
145 PE4.Data
144 PE4.Control
143 PE4.Pull-up_Enable
142 PE5.Data
141 PE5.Control
140 PE5.Pull-up_Enable
139 PE6.Data
138 PE6.Control
137 PE6.Pull-up_Enable
136 PE7.Data
135 PE7.Control
134 PE7.Pull-up_Enable
Table 113. ATmega329/649 Boundary-scan Order, 64-pin (Continued)
Bit Number Signal Name Module
